Chapter 7 Optional AccessoriesCP2000
7-18
Unit: mm
Input AC reactor
Delta part #
Dimensions
DR065AP162 Refer to the diagram above
Installing screw M6
PE M6
Tightening torque: 3±1.5 Nm
Figure 7-9
Table 7-25
