Chapter 1 IntroductionCP2000
1-18
Frame F
F2: VFD1600CP43A-21; VFD1850CP43B-21; VFD1600CP63A-21; VFD2000CP63A-21
H1
H2
S1
S1
D2
W
W1
D
D1
H3
H
S2
S3
3 2 1 2 2 2 3 1
See Detail A
See Detail B
Detail A (Mounting Hole)
Detail B (Mounting Hole)
Unit: mm [inch]
Frame W H D W1 H1 H2 H3 D1* D2 S1 S2 S3
F2
420.0
[16.54]
940.0
[37.00]
300.0
[11.81]
380.0
[14.96]
800.0
[31.50]
770.0
[30.32]
717.0
[28.23]
124.0
[4.88]
18.0
[0.71]
13.0
[0.51]
25.0
[0.98]
18.0
[0.71]
Frame Φ1 Φ2 Φ3
F2
92.0
[3.62]
35.0
[1.38]
22.0
[0.87]
D1*: Flange mounting
See Detail
A
See Detail B
Detail A
(
Mountin
g
Hole
)
Detail B
(
Mountin
g
Hole
)
