13
!
Figure 4-3 Correct and incorrect installation illustration
CAUTION
The location and hardware should be a solid surface or a firm
holder that suitable for the weight of inverter.
Suggested to install the inverter to the location which offers
free and safe access. It would streamline the service and
maintenance
Please leave an appropriate gap in between when installing
singe/ several solar inverter systems.
Please install solar inverter at an eye level to allow easy
observation for operation and parameter setting.
