Delta RPI-H3 Owner's Manual

50
Pin Function
1 Digital input 1
2 Digital input 2
3 Digital input 3
4 Digital input 4
5 Output 1
6 Output 2
Country = Italy & Italy with SPI
Function D1 D2 D3 D4 Output 1 Output 2
No function 0 0 0 0 1 1
Remote off 1 0 0 0 1 1
Narrow
frequency limit.
0 1 0 0 1 1
Note: 1 = Relay is closed, 0 = Relay is open.
Country = Germany
Function D1 D2 D3 D4 Output 1 Output 2
No function 0 0 0 0 1 1
Active power =
0%
1 0 0 0 1 1
Active power =
30%.
0 1 0 0 1 1
Active power =
60%
0 0 1 0 1 1
Active power =
100%
0 0 0 1 1 1
Note: 1 = Relay is closed, 0 = Relay is open.
Cable requirements:
 Conductor cross-section: 0.205 mm² (AWG24) ~ 0.081 mm².(AWG28)
 Outside diameter of cable : 3.8mm ~ 5.2mm
 Please refer to UL 2464 computer cable guideline
