Delta RPI-M15A Quick Installation Guide

23
Quick installation guide for RPI M15A M20A inverters
Mechanical Design RPI-M15A RPI-M20A
Dimensions(WxHxD) 612 x 625 x 278 mm
Weight 43 kg
Cooling Fans
AC Connector type AC Plug Amphenol C16-3
DC Connector type Multi-Contact MC4
Communication interfaces 2xRS485,1xDrycontact,1xEPO
General Specication RPI-M15A RPI-M20A
Delta model name RPI-M15A RPI-M20A
Deltapartnumber RPI153FA0E0000 RPI203FA0E0000
Maximumefciency 98.3% 98.4%
EUefciency 97.9% 98.1%
Operatingtemperaturerange -25 ... +60 °C
Operatingtemperaturerangewithoutderating -25 ... +40 °C -25 ... +47 °C
4)
Storage temperature range -25 ... +60 °C
Relative humidity 0 ... 100 %, non-condensing
Maximum operating altitude 2000mabovesealevel
Standards and Directives RPI-M15A RPI-M20A
Protection degree IP65
Safety class I
Pollution degree II
Overloadbehavior Current limitation; power limitation
Safety IEC62109-1/-2,CEcompliance
EMC EN 61000-6-2, EN 61000-6-3
Immunity IEC61000-4-2/-3/-4/-5/-6/-8
Harmonics EN 61000-3-2
Variationsandicker EN 61000-3-3
1)
IEC 60664-1, IEC 62109-1
2)
Forcosphi=1(VA=W)
3)
ACvoltageandfrequencyrangewillbeprogrammedaccordingtotheindividualcountryrequirements.
4)
Deratingstartingat47°CwithnominalDCvoltageandACoutputpowerof21kVA
