Delta TP Series User Manual

- 2 -
y Front View and Right Side View (Units: mm, [ ]: inch)
Figure3
175.8 [6.921]
9
5
[
3
.
7
4
]
37
[1.457]
1
0
8
.
6
[
4
.
2
7
6
]
y Mounting Dimensions (Panel Cutout)
(Units: mm, [ ]: inch)
y Top View (Units: mm, [ ]: inch)
Figure4
162.7~164.0 [6.4055~6.4567]
Thickness Range 0.5~5mm
9
5
.
5
~
9
7
.
0
[
]
3
.
7
5
9
8
~
3
.
8
1
8
8
Figure5
162.2 [6.386]
2
9
.5
[1
.1
6
1
]
7
.
5
[
0
.
2
9
5
]
 Model Name and Serial Number
TP04
G
--
Graphic mode
C: CE only
Series name
Model type
Safety approval
BL C
 Function Specifications
Model
Spec.
TP04G-BL-C
Screen type / Display
color
STN-LCD / Monochrome
Driver Delta products
Function / Numeric
keys
0~9, ESC, F, Enter and Left/Right/Up/Down Keys
Alarm LED indicator
(RED)
Power on indication (Blink for three times)
Communication error alarm
Special indication by user programming
Backlight
The automatic turn-off time of backlight: 1 ~ 99 minutes (0 = do not
turn off) (Life span of backlight is about 50,000 hours at 25°C)
Contrast adjustment Set by software, 10 levels of adjustment
Language / Font
ASCII: (Code page 850) Alphanumeric (including European char.)
Traditional Chinese fonts
Simplified Chinese fonts
Resolution 192 × 64 dots
Display range 101.8mm(W) × 35.24mm(H); 4.1” (diagonal preferred)
Font size ASCII: 5×8, 8×8, 8×12, 8×16
Display text
5×8 dots 38 characters × 8 rows
8×8 dots 24 characters × 8 rows
8×12 dots 24 characters × 5 rows
8×16 dots 24 characters × 4 rows

Delta TP Series Specifications

General

Power Supply	24VDC
Communication Ports	RS-232, RS-485, Ethernet
Operating Temperature	0°C to 50°C
Protection Rating	IP65
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% RH (non-condensing)
Resolution	800 x 480 pixels
