Chapter 1 Introduction
1-13
1.8.2
Wiring Input Terminals
The power supplied to input terminals are DC power. There are two types of current. They are sinking current
and sourcing current.
Sinking current
S/S
X0
I/
O
Internal
circuit
Sourcing current
Internal
circuit
S/S
X0
I/
O
1.8.3
Wiring Relay Output Terminals
Y0
C0
Relay output
AC load
AC power
