Page #1103 background image
Chapter 16 PLC Function ApplicationsC2000 Plus
16-40
PDO reflection length setting:
Special D Description of Function
Default:
R/W
D2034+100*n Real-time transmission setting of slave station number n
000AH
RW
D2067+100*n Real-time reception setting of slave station number n
0000H
RW
16-5-4 PLC Communication address
Device Range Type Address (Hex)
X 00–37 (Octal) bit 0400–041F
Y 00–37 (Octal) bit 0500–051F
T 00–159 bit/word 0600–069F
M 000–799 bit 0800–0B1F
M 1000–1079 bit 0BE8–0C37
C 0–79 bit/word 0E00–0E47
D 00–399 word 1000–118F
D 1000–1099 word 13E8–144B
D 2000–2799 word 17D0–1AEF
Command code that can be used
Function Code Description of Function Function target
01 Coil status read Y,M,T,C
02 Input status read X,Y,M,T,C
03 Read single unit of data T,C,D
05 Compulsory single coil status change Y,M,T,C
06 Write single unit of data T,C,D
0F Compulsory multiple coil status change Y,M,T,C
10 Write multiple units of data T,C,D
NOTE: When PLC functions have been activated, the C2000 Plus can match PLC and drive
parameters; this method employs different addresses, drives (default station number is 1, PLC sets
station number as 2)
