Appendix A. Modbus ProtocolC2000 Plus
A-13
Function
Name
Modbus
Address
Attribute
(Function
Code)
Size Description
The co-
rresponding
CPU pin
status of
digital input
2213H R(03H)
U16
The corresponding CPU pin status of digital input (d.)
(see NOTE 3 in Pr.00-04)
The co-
rresponding
CPU pin
status of
digital
output
2214H R(03H)
The corresponding CPU pin status of digital output (O.)
(see NOTE 4 in Pr.00-04)
Actual
motor
position
2215H R(03H)
Number of actual motor revolution (PG1 of PG card) (P.) it starts
from 9 when the actual operation direction is changed or the
keypad displays at stop is 0. The maximum is 65535
Pulse input
frequency
2216H R(03H) Pulse input frequency (PG2 of PG card) (XXX.XX Hz)
Pulse input
position
2217H R(03H)
Pulse input position (PG card PG2), the maximum setting is
65535.
Tracing
error of
pulse
command in
position
control
2218H R(03H) Position command tracing error
Overload
counter
2219H R(03H) Display times of counter overload (XXX.XX %)
GFF 221AH R(03H) GFF (XXX.XX%)
DC bus
voltage
ripples
221BH R(03H) DCBUS voltage ripples (XXX.X V)
PLC
register
221CH R(03H) PLC register D1043 data (C)
Magnetic
pole zone
221DH R(03H) Number of poles of a permanent magnet motor
Display of
user-
defined
output
221EH R(03H)
U16
User page displays the value in physical measure
Pr.00-05
gain value
221FH R(03H) Output Value of Pr.00-05 (XXX.XX Hz)
Number of
motor runs
2220H R(03H)
Number of motor runs when drive operates (saves when drive
stops, and resets to zero when operating)
Operating
position of
the motor
2221H R(03H)
Operating position of the motor (saves when drive stops, and
resets to zero when operating)
