Delta VFD040C43A-21 User Manual

Chapter 7 Optional AccessoriesC2000 Plus
7-39
380V–460V, 50/60 Hz
Model HP
Heavy Duty Super Heavy Duty
Rated
current
(Arms)
Saturation
current
(Arms)
DC reactor
(mH)
DC reactor
Delta Part #
Rated
current
(Arms)
Saturation
current
(Arms)
DC reactor
(mH)
DC reactor
Delta Part #
VFD007C43A-21
1 3 5.4 18.709 DR003D1870 1.7 3.4 33.016 N/A
VFD015C43A-21
2 4 7.2 14.031 DR004D1403 3 6 18.709 DR003D1870
VFD022C43A-21
3 6 10.8 9.355 DR006D0935 4 8 14.031 DR004D1403
VFD037C43A-21
5 9 16.2 6.236 DR009D0623 6 12 9.355 DR006D0935
VFD040C43A-21
5 10.5 18.9 5.345 DR010D0534 9 18 6.236 DR009D0623
VFD055C43A-21
7.5 12 21.6 4.677 DR012D0467 10.5 21 5.345 DR010D0534
VFD075C43A-21
10 18 32.4 3.119 DR018D0311 12 24 4.677 DR012D0467
VFD110C43A-21
15 24 43.2 2.338 DR024D0233 18 36 3.119 DR018D0311
VFD150C43A-21
20 32 57.6 1.754 DR032D0175 24 48 2.338 DR024D0233
VFD185C43A-21
25 38 68.4 1.477 DR038D0147 32 64 1.754 DR032D0175
VFD220C43A-21
30 45 81 1.247 DR045D0124 38 76 1.477 DR038D0147
VFD300C43A-21
40 60 108 0.935 DR060DP935 45 90 1.247 DR045D0124
575V
Model HP
Rated current
(Arms)
Saturation
current
(Arms)
4% DC reactor
(mH)
Light
dut
y
Normal
dut
y
Heavy
dut
y
Light
dut
y
Normal
dut
y
Heavy
dut
y
VFD015C53A-21 2 3 2.5 2.1 4.2 20.336 24.404 29.052
VFD022C531-21 3 4.3 3.6 3 5.9 14.188 16.947 20.336
VFD037C53A-21 5 6.7 5.5 4.6 9.1 9.106 11.093 13.263
VFD055C53A-21 7.5 9.9 8.2 6.9 13.7 6.163 7.440 8.842
VFD075C53A-21 10 12.1 10 8.3 16.5 5.042 6.101 7.351
VFD110C53A-21 15 18.7 15.5 13 25.7 3.263 3.936 4.693
VFD150C53A-21 20 24.2 20 16.8 33.3 2.521 3.050 3.632
690V
Model HP
Rated current
(Arms)
Saturation current
(Arms)
4% DC reactor
(mH)
Light
dut
y
Normal
dut
y
Heavy
dut
y
Light
dut
y
Normal
dut
y
Heavy
dut
y
Light
dut
y
Normal
dut
y
Heavy
dut
y
VFD185C63B-21 25 24 20 14 28.8 30.0 25.2 3.661 4.393 6.275
VFD220C63B-21 30 30 24 20 36.0 36.0 36.0 2.928 3.661 4.393
VFD300C63B-21 40 36 30 24 43.2 45.0 43.2 2.440 2.928 3.661
VFD370C63B-21 50 45 36 30 54.0 54.0 54.0 1.952 2.440 2.928
The table below shows the models with built-in DC reactors:
Frame D
VFD450C63B-00; VFD550C63B-00; VFD450C63B-21; VFD550C63B-21
Frame E
VFD750C63B-00; VFD900C63B-00; VFD1100C63B-00; VFD1320C63B-00
VFD750C63B-21;
VFD900C63B-21; VFD1100C63B-21; VFD1320C63B-21
Frame F
VFD1600C63B-00; VFD2000C63B-00; VFD1600C63B-21; VFD2000C63B-21
Frame G
VFD2500C63B-00; VFD3150C63B-00; VFD2500C63B-21; VFD3150C63B-21
Frame H
VFD4000C63B-00; VFD4500C63B-00; VFD5600C63B-00; VFD6300C63B-00
VFD4000C63B-21;
VFD4500C63B-21; VFD5600C63B-21; VFD6300C63B-21
Table 7-42
Table 7-43
Table 7-44
Table 7-45
