Delta VFD040C43A-21 User Manual

Chapter 7 Optional AccessoriesC2000 Plus
7-41
DC reactor Delta Part #
A
(mm)
B
(mm)
C
(mm)
D
(mm)
E
(mm)
R
(mm)
DR003D1870 79 78 112 64±2 56±2 9.5*5.5
DR004D1403 79 92 112 64±2 69.5±2 9.5*5.5
DR006D0935 79 92 112 64±2 69.5±2 9.5*5.5
DR009D0623 79 112 112 64±2 89.5±2 9.5*5.5
DR010D0534 99 93 128 79±2 70±2 9.5*5.5
DR012D0467 99 105 128 79±2 82.5±2 9.5*5.5
DR018D0311 117 110 144 95±2 87±2 10*6.5
DR024D0233 117 120 144 95±2 97±2 10*6.5
DR032D0175 117 140 157 95±2 116.5±2 10*6.5
DR038D0147 136 135 172 111±2 112±2 10*6.5
DR045D0124 136 135 173 111±2 112±2 10*6.5
DR060DP935 136 150 173 111±2 127±2 10*6.5
The table below shows the THDi specification when using Delta’s drives to work with AC/DC reactors:
Current
Harmonics
Models without built-in DC reactor Models with built-in DC reactor
No AC/DC
reactor
3% input AC
reactor
5% input AC
reactor
4% DC reactor
No AC/DC
reactor
3% input AC
reactor
5% input AC
reactor
5th 73.3% 38.5% 30.8% 25.5% 31.16% 27.01% 25.5%
7th 52.74% 15.3% 9.4% 18.6% 23.18% 9.54% 8.75%
11th 7.28% 7.1% 6.13% 7.14% 8.6% 4.5% 4.2%
13th 0.4% 3.75% 3.15% 0.48% 7.9% 0.22% 0.17%
THDi 91% 43.6% 34.33% 38.2% 42.28% 30.5% 28.4%
Table 7-47
NOTE: The THDi specification listed here may be slightly different from the actual THDi, depending on the installation and
environmental conditions (wires, motors).
Table 7-46
