Delta VFD040C43A-21 User Manual

Chapter 7 Optional AccessoriesC2000 Plus
7-67
D
B
C
E
F
H
G
Figure 7-45
Unit: mm (inch)
Model A B C D E F G(Ø) H Torque
RF002X00A
200
(7.874)
172.5
(6.791)
90
(3.543)
78
(3.071)
55.5
(2.185)
184
(7.244)
5.5
(0.217)
22
(0.866)
<45 kgf/cm
2
Figure 7-46
Unit: mm (inch)
Model A B C D E F G(Ø) H I
RF300X00A
241
(9.488)
217
(8.543)
114
(4.488)
155
(6.102)
42
(1.654)
220
(8.661)
6.5
(0.256)
7.0
(0.276)
20
(0.787)
Magnetic Ring
Model number: T60006-L2040-W453
Unit: mm
Figure 7-47
Table 7-75
Table 7-76
