Chapter 8 Option CardsC2000 Plus
8-53
8-17-5 To set the communication parameters when C2000 Plus connects with PROFINET
When you operate C2000 Plus through CMC-PN01, set up the communication card as the source
of C2000 Plus controls and settings. You need to use the keypad to configure the following parameter
addresses to the corresponding values:
8-17-6 LED indicator introduction
Name Indicator status Indication
Ready out
indicator
Yellow LED
Always ON PN Stack starts normally
Flashing
PN Stack starts normally, and waiting for syncing with
MCU
OFF PN Stack failed to start
MT out
indicator
Green LED - -
SD indicator Red LED - -
BF out
indicator
Red LED
Always ON Connection with PROFINET Controller is interrupted
Flashing
Connection is in normal state, but the communication
with PROFINET Controller is abnormally
OFF
Connection with PROFINET Controller is in normal
state
ACT PHY1
indicator
Orange LED
Always ON
It’s online, and exchanging the data with Master
normally
Flashing It’s offline, but hand shaking the data with Master
OFF Initial state
LINK PHY1
indicator
Green LED
Always ON Internet connection is in normal state
OFF Doesn’t connect to network
ACT PHY2
indicator
Orange LED
Always ON
It’s online, and exchanging the data with Master
normally
Flashing It’s offline, but hand shaking the data with Master
OFF Initial state
LINK PHY2
indicator
Green LED
Always ON Internet connection is in normal state
OFF Doesn’t connect to network
Parameters Setting value Description
00-20 8
The frequency command is controlled by communication card
00-21 5
The frequency command is controlled by communication card
09-30 1
Use decoding method (60xx or 20xx)
09-60 12
Communication card identification:
When CMC-PN01 communication card is connected, the value of
this parameter displays “12”.
