Chapter 12 Descriptions of Parameter SettingsC2000 Plus
12.1-01-14
Pulse-train positioning control diagram:
Pulse-train positioning position control:
The pulse-train positioning position control uses the pulse-train command as the position
command for position control.
The pulse-train command can be either an open-collector signal or a differential signal.
