ARM (Kp) Gain
Default: 1.00
Settings 0.00–3.00
If Pr.00-11 = 8 (SynRM sensorless), then the default becomes 0.40.
10-36
ARM (Ki) Gain
Default: 0.20
Settings 0.00–3.00
Active Magnetic Regulator Kp / Ki, affects the response of magnetic regulation in the low
magnetic area.
If entering the low magnetic area and the input voltage (or DC bus) plummets (e.g. an unstable
power net causes instant insufficient voltage, or a sudden load that makes DC bus drop), which
causes the ACR diverge and oc, then increase the gain. If the Id value of a spur creates large
noise in high-frequency output current, decrease the gain to reduce the noise. Decrease the gain
will slow down the response.
If Pr.00-11 = 8 (SynRM sensorless), then the default becomes 2.00.
10-37
PM Sensorless Control Word
Default: 0000h
Settings 0000–FFFFh
bit No. Function Description
5 Choose a control mode to stop
0: When lower than Pr.10-40, ramp to stop
1: When lower than Pr.10-40, coast to stop
10-39
Frequency to Switch from I/F Mode to PM Sensorless Mode
(Frequency to Switch from IMVF Mode to IMFOCPG Mode when Pr.11-00
bit11 = 1 in IMFOCPG Mode)
Default: 20.00
Settings 0.00–599.00 Hz
Set the frequency for switching from low frequency to high frequency, and sets the switch point
for high and low frequencies of the speed observer.
If the switch frequency is too low, the motor does not generate enough back-EMF to let the speed
observer measure the right position and speed of the rotor, causing stall and oc when running
at the switch frequency.
The active range of I/F is too wide if the switch frequency is too high, this generates a larger
current and cannot save energy. (If the current value for Pr.10-31 is too high, the high switch
frequency makes the drive continue to output with Pr.10-31 setting value.)
If Pr.00-11 = 8 (SynRM sensorless), then the default becomes 10.00 Hz.
When Pr.11-00 bit11 = 1, Pr.10-39 is the frequency for switching from IMVF to IMFOCPG control
modes.
