Delta VFD040C43A-21 User Manual

Chapter 14 Fault Codes and DescriptionsC2000 Plus
14-14
ID* Display on LCD Keypad Fault Name Fault Descriptions
10
Over-voltage at stop
(ovS)
Over-voltage at stop
Action and Reset
Action condition
230V models: 410 V
DC
460V models: 820 V
DC
575V models: 1116 V
DC
690V models: 1318 V
DC
Action time Act immediately when DC bus voltage is higher than the condition
Fault treatment parameter N/A
Reset method Manual reset
Reset condition Reset only when DC bus voltage is lower than 90% of over-voltage condition
Record Yes
Cause Corrective Actions
Power voltage is too high
Check if the input voltage is
within the rated AC motor drive input voltage range,
and check for possible voltage spikes.
ON/OFF switch action of phase-in
capacitor in the same power
system
If the phase-in capacitor or active power supply unit
activates in the same power
system, the input voltage may surge abnormally in a s
hort time. In this case,
install an AC reactor.
Incorrect wiring of brake resistor or
brake unit
Check the wiring of brake resistor or brake unit.
Malfunction caused by
interference
Verify the wiring of the control circuit and wiring/grounding of the main circuit to
prevent interference.
Hardware failure in voltage
detection
Check if other fault code such as cd1–cd3 occur after cycling the power.
If yes,
return to the factory for repair.
Motor ground fault
The ground short
circuit current charges the capacitor in the main circuit through
the power. Check if
there is ground fault on the motor cable, wiring box and its
internal terminals.
Troubleshoot the ground fault.
