Chapter 10 Auto-tuning Process | VFD-ED
10-3-3-2 Settings for Induction Motor (IM)
Pr.05-01 Motor Rated Current
Press
Press
 Set this value according to the rated motor frequency from the motor nameplate.
Pr.05-02 Motor Rated Power
Press
Press
 Set the rated power of the motor. The default is the power of the drive.
Pr.05-03 Motor Rated Speed
Press
Press
 Sets the motor rated speed from the value on the motor nameplate.
To Next Page
