Chapter 11 Summary of Parameter Settings | VFD-ED
11-6
01 Basic Parameters
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
01-00
Maximum Output
Frequency
5.00–299.00 Hz
60.00/
50.00
○ ○ ○ ○ ○
01-01
First Output Frequency
Setting (base frequency /
motor’s rated frequency)
0.00–299.00 Hz
60.00/
50.00
○ ○ ○ ○ ○
01-02
First Output Voltage Setting
(base voltage/
motor’s rated voltage)
230V models: 0.1–255.0 V
460V models: 0.1–510.0 V
220.0
440.0
○ ○
○ ○ ○
01-03
Second Output Frequency
Setting
0.00–299.00 Hz 0.50 ○ ○
 01-04
Second Output Voltage
Setting
230V models: 0.1–255.0 V
460V models: 0.1–510.0 V
5.0
10.0
○ ○
01-05
Third Output Frequency
Setting
0.00–299.00 Hz 0.50 ○ ○
 01-06
Third Output Voltage
Setting
230V models: 0.1–255.0 V
460V models: 0.1–510.0 V
5.0
10.0
○ ○
01-07
Fourth Output Frequency
Setting
0.00–299.00 Hz 0.00 ○ ○ ○ ○
 01-08
Fourth Output Voltage
Setting
230V models: 0.1–255.0 V
460V models: 0.1–510.0 V
5.0
10.0
○ ○ ○
01-09
Starting Frequency
0.00–299.00 Hz
0.50
○
○
○
○
 01-10
Output Frequency Upper
Limit
0.00–299.00 Hz 299.00 ○ ○ ○ ○ ○
 01-11
Output Frequency Lower
Limit
0.00–299.00 Hz 0.00 ○ ○ ○ ○ ○

01-12
Accel. Time 1
0.00–600.00 sec.
3.00
○ ○ ○ ○ ○

01-13
Decel. Time 1
0.00–600.00 sec.
2.00
○
○
○
○
○

01-14
Accel. Time 2
0.00–600.00 sec.
3.00
○
○
○
○
○

01-15
Decel. Time 2
0.00–600.00 sec.
2.00
○
○
○
○
○

01-16
Accel. Time 3
0.00–600.00 sec.
3.00
○
○
○
○
○

01-17
Decel. Time 3
0.00–600.00 sec.
2.00
○
○
○
○
○

01-18
Accel. Time 4
0.00–600.00 sec.
3.00
○
○
○
○
○

01-19
Decel. Time 4
0.00–600.00 sec.
2.00
○
○
○
○
○

01-20
JOG Acceleration Time
0.00–600.00 sec.
1.00
○
○
○
○
○

01-21
JOG Deceleration Time
0.00–600.00 sec.
1.00
○
○
○
○
○

01-22
JOG Frequency
0.00–299.00 Hz
6.00
○
○
○
○
○
 01-23
Switch Frequency between
First and Fourth Accel./
Decel.
0.00–299.00 Hz 0.00 ○ ○ ○ ○ ○
 01-24
S-curve for Acceleration
Begin Time S1
0.00–25.00 sec. 1.00 ○ ○ ○ ○ ○
 01-25
S-curve for Acceleration
Arrival Time S2
0.00–25.00 sec. 1.00 ○ ○ ○ ○ ○

01-26
S-curve for Deceleration
0.00–25.00 sec.
1.00
○
○
○
○
○
