Chapter 11 Summary of Parameter Settings | VFD-ED
11-11
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
45: Reserved
46: Retrying after a fault has occurred
indication
○ ○ ○ ○ ○
47: Direct docking mode only
◆
48: Control output of MPSCC (Motor
Phase Short Circuit Contactor)
○ ○ ○ ○ ○
49: Emergency power mode action
○
○
○
○
○
50: Speed reached Pr.02-34
○
○
○
○
○
51: Brake torque test finished
○
○
○
○
○
52: AFE reset
○
○
○
○
○
02-21–02-22
Reserved

02-23
Multi-output Direction
0–65535
0
○
○
○
○
○
02-24
Serial Start Signal
Selection
0: According to FWD/REV signal
1: According to Enable drive function
signal
0 ○ ○ ○ ○ ○
 02-25
Desired Frequency
Reached 1
0.00–299.00 Hz
60.00/
50.00
○ ○ ○ ○ ○
 02-26
Desired Frequency
Reached Width 1
0.00–299.00 Hz 2.00 ○ ○ ○ ○ ○
 02-27
Desired Frequency
Reached 2
0.00–299.00 Hz
60.00/
50.00
○ ○ ○ ○ ○
 02-28
Desired Frequency
Reached Width 2
0.00–299.00 Hz 2.00 ○ ○ ○ ○ ○
02-29
Brake Release Delay
Time when Elevator
Starts
0.000–65.000 sec. 0.250 ○ ○ ○ ○ ○
02-30
Brake Engage Delay
Time when Elevator
Stops
0.000–65.000 sec. 0.250 ○ ○ ○ ○ ○
 02-31
Magnetic Contactor
Contracting Delay Time
between Drive and
Motor
0.010–65.000 sec. 0.200 ○ ○ ○ ○ ○
 02-32
Magnetic Contactor
Release Delay Time
between Drive and
Motor
0.010–65.000 sec. 0.200 ○ ○ ○ ○ ○
 02-33
External Terminal
Output Current Level
0–100% (motor drive rated current) 0 ○ ○ ○ ○ ○
 02-34
External Terminal
Output Speed Limit
0.00–299.00 Hz (this is motor speed
when using with PG)
NOTE: The setting range and unit of
Pr.02-34 varies with Pr.00-10 settings.
See Chapter 12 for details.
0.00 ○ ○ ○ ○ ○
 02-35
Mechanical Brake
Detection Time
0.00–10.00 sec. 0.00 ○ ○ ○ ○ ○
