12 Descriptions of Parameter Settings | VFD-ED
When you set Pr.06-79 to 0:
Disable the operation direction count function and clear parameters (Pr.06-75, 06-76, and 06-78), and add
one time to the number of times for single operation reset (pr.06-77).
When you set Pr.06-79 to 1:
Enable the operation direction count function and add one time to the permanent operation direction
count and single operation direction count whenever the operation direction changes. If the single
operation direction count is larger than Pr.06-78, SERV warning code will be triggered and continues
operation.
When you set Pr.06-79 to 2:
Enable the operation direction count function and add one time to the permanent operation direction
count and single operation direction count whenever the operation direction changes. If the single
operation direction count is larger than Pr.06-78, SERV fault code will be triggered before operation.
Output Frequency when Fault 2 Occurred
Control Mode
VF VFPG SVC FOCPG FOCPM Default: Read only
Settings 0.00–655.35 Hz
DC Bus Voltage when Fault 2 Occurred
Control Mode
VF VFPG SVC FOCPG FOCPM Default: Read only
Settings 0.0–6553.5 V
Output Current when Fault 2 Occurred
Control Mode
VF VFPG SVC FOCPG FOCPM Default: Read only
Settings 0.00–655.35 Amps
IGBT Temperature when Fault 2 Occurred
Control Mode
VF VFPG SVC FOCPG FOCPM Default: Read only
Settings -3276.8–3276.7ºC
Output Frequency when Fault 3 Occurred
Control Mode
VF VFPG SVC FOCPG FOCPM Default: Read only
Settings 0.00–655.35 Hz
DC Bus Voltage when Fault 3 Occurred
Control Mode
VF VFPG SVC FOCPG FOCPM Default: Read only
Settings 0.0–6553.5 V
Output Current when Fault 3 Occurred
Control Mode
VF VFPG SVC FOCPG FOCPM Default: Read only
Settings 0.00–655.35 Amps
IGBT Temperature when Fault 3 Occurred
Control Mode
VF VFPG SVC FOCPG FOCPM Default: Read only
Settings -3276.8–3276.7ºC
