Chapter 6 Optional Accessories | VFD-ED
6-4
PM Elevator System (Using Delta’s Brake Resistor)
Voltage
Applicable Delta’s
Motor Drive
125% Braking Torque/30% ED*
1
Max. Braking Torque
HP Model
Braking
Torque*
2
(kg-m)
Brake Unit Delta’s Brake Resistor
*3
Braking
Current
(A)
*4
Min.
Resistor
Value (Ω)
Max. Total
Braking
Current
(A)
Peak
Power
(kW)
VFDB # Part No. #
Configurat
ion
230V
3 VFD022ED21S 1.5 BR1K0W050 1 7.6 38.0 10.0 3.8
5 VFD037ED21S 2.5 BR1K0W016 2 2 in series 11.9 19.0 20.0 7.6
5 VFD040ED23S 2.5 BR1K0W016 2 2 in series 11.9 19.0 20.0 7.6
7.5 VFD055ED23S 3.7 BR1K0W050 2 2 parallel 15.2 15.6 24.4 9.3
10 VFD075ED23S 5.1 BR1K0W050 3 3 parallel 22.8 11.5 33.0 12.5
15 VFD110ED23S 7.5 BR1K0W050 4 4 parallel 30.4 9.5 40.0 15.2
20 VFD150ED23S 10.2 BR1K0W050 5 5 parallel 38.0 8.3 46.0 17.5
25 VFD185ED23S 12.2 BR1K5W039 5 5 parallel 48.7 5.8 66.0 25.1
30 VFD220ED23S 14.9 BR1K5W039 6 6 parallel 58.5 5.8 66.0 25.1
40 VFD300ED23S 20.3 2015 2 BR1K0W050 10 10 parallel 76.0 4.8 80.0 30.4
50 VFD370ED23S 25.1 2022 2 BR1K0W050 14 14 parallel 106.4 3.2 120.0 45.6
460V
5 VFD040ED43S 2.7 BR1K0W050 2 2 in series 7.6 54.3 14.0 10.6
7.5 VFD055ED43S 3.7 BR1K0W050 2 2 in series 7.6 48.4 15.7 11.9
10 VFD075ED43S 5.1 BR1K0W020 3 3 in series 12.7 39.4 19.3 14.7
15 VFD110ED43S 7.5 BR1K0W050 4
2 in series
2 parallel
15.2 30.8 24.7 18.8
20 VFD150ED43S 10.1 BR1K5W039 4
2 in series
2 parallel
19.5 25.0 30.4 23.1
25 VFD185ED43S 12.5 BR1k2W039 6
2 in series
3 parallel
29.2 20.8 36.5 27.7
30 VFD220ED43S 14.9 BR1K5W039 6
2 in series
3 parallel
29.2 19.0 40.0 30.4
40 VFD300ED43S 20.3 BR1K5W039 8
2 in series
4 parallel
39.0 14.1 54.0 41.0
50 VFD370ED43S 25.0 4045 1 BR1K5W039 10
2 in series
5 parallel
48.7 13.8 55.0 41.8
60 VFD450ED43S 30.4 4030 2 BR1K5W039 12
2 in series
6 parallel
58.5 10.3 74.0 56.2
75 VFD550ED43S 37.2 4045 2 BR1k2W039 16
2 in series
8 parallel
77.9 6.9 110.0 83.6
100 VFD750ED43S 50.7 4110 1 BR1k2W039 22
2 in series
11 parallel
107.2 6.4 118.0 89.7
Table 6-3
*
1
Calculation of 125% braking torque: (kW)*125%*0.8; where 0.8 is the motor efficiency.
Since there is a resistor power consumption limit, the longest operation time for 30% ED is 30 seconds (ON: 30
seconds / OFF: 70 seconds).
*
2
The calculation of the brake resistor is based on a four-pole motor (1800 rpm).
*
3
To dissipate heat, mount a resistor of 400 W or lower to a frame to keep the surface temperature below 250°C
(482°F). Fix a resistor of 1000 W or higher to a surface to keep the surface temperature below 600°C (1112°F).
(If the resistor temperature is higher than 350°C, install extra cooling. If the resistor temperature is higher than
the temperature limit, increase the size of the resistor.)
*4
The calculation of the braking current is based on Delta’s brake resistor and default braking voltage (220V
AC
:
380V
DC
; 440V
AC
: 760V
DC
).
