Chapter 11 Summary of Parameter SettingsC2000-HS
11-2
Pr. Parameter Name Setting Range Default
Pr. 10-01) (Unit: PLS)
10: Display PID feedback (b) (Unit: %)
11: Display AVI in % (1.) (Unit: %)
12: Display ACI in % (2.) (Unit: %)
13: Display AUI in % (3.) (Unit: %)
14: Display temperature of IGBT (i.) (Unit: °C)
15: Display temperature of capacitance (c.)
(Unit: °C)
16: The status of digital input (ON / OFF) (i)
17: The status of digital output (ON / OFF) (o)
18: Multi-step speed (S)
19: The corresponding CPU pin status of digital
input (d)
20: The corresponding CPU pin status of digital
output (0.)
21: Actual motor position (PG1 of PG card) (P.)
The maximum value is 32bits display
22: Pulse input frequency (PG2 of PG card) (S.)
23: Pulse input position (PG2 of PG card) (q.)
The maximum value is 32bits display
24: Position command tracing error (E.)
25: Overload count (0.00–100.00%) (o.) (Unit: %)
26: Ground fault GFF (G.) (Unit: %)
27: DC BUS voltage ripple (r.) (Unit: V
DC
)
28: Display PLC register D1043 data (C)
29: Display PM pole section (EMC-PG01U
application) (4.)
30: Display output of user defined (U)
31: Display Pr. 00-05 user gain (K)
32: Number of actual motor revolution during
operation (PG card plug in and Z phase signal
input) (Z.)
33: Motor actual position during operation (when PG
card is connected) (q)
34: Operation speed of fan (F.) (Unit: %)
35: Control mode display:
0 = Speed control mode (SPD)
1 = Torque control mode (TQR) (t.)
36: Present operating carrier frequency of drive (Hz)
(J.)
