Chapter 11 Summary of Parameter SettingsC2000-HS
11-18
Pr. Parameter Name Setting Range Default

03-29 ACI terminal input selection
0: 4–20mA
1: 0–10V
2: 0–20mA
0
03-30
PLC analog output terminal
status
Monitor the status of PLC analog output terminals
Read
only

03-31 AFM2 output selection
0: 0–20mA output
1: 4–20mA output
0

03-32 AFM1 DC output setting level 0.00–100.00% 0.00

03-33 AFM2 DC output setting level 0.00–100.00% 0.00

03-35 AFM1 filter output time 0.00–20.00 sec. 0.01

03-36 AFM2 filter output time 0.00–20.00 sec. 0.01

03-44
Multi-function MO output by AI
level source
0: AVI
1: ACI
2: AUI
0

03-45 AI upper level -100.00–100.00% 50.00

03-46 AI lower level -100.00–100.00% 10.00

03-50 Analog input curve selection
0: Regular curve
1: Three-point curve of AVI
2: Three-point curve of ACI
3: Three-point curve of AVI & ACI
4: Three-point curve of AUI
5: Three-point curve of AVI & AUI
6: Three-point curve of ACI & AUI
7: Three-point curve of AVI & ACI & AUI
0

03-51 AVI lowest point
Pr. 03-28=0, 0.00–10.00V
Pr. 03-28=1, 0.00–20.00mA
Pr. 03-28=2, 0.00–20.00mA
0.00
0.00
4.00

03-52 AVI proportional lowest point -100.00–100.00% 0.00

03-53 AVI mid-point
Pr. 03-28=0, 0.00–10.00V
Pr. 03-28=1, 0.00–20.00mA
Pr. 03-28=2, 0.00–20.00mA
5.00
10.00
12.00

03-54 AVI proportional mid-point -100.00–100.00% 50.00

03-55 AVI highest point
Pr. 03-28=0, 0.00–10.00V
Pr. 03-28=1, 0.00–20.00mA
Pr. 03-28=2, 0.00–20.00mA
10.00
20.00
20.00

03-56 AVI proportional high point -100.00–100.00% 100.00

03-57 ACI lowest point
Pr. 03-29=0, 0.00–20.00mA
Pr. 03-29=1, 0.00–10.00V
Pr. 03-29=2, 0.00–20.00mA
4.00
0.00
0.00

03-58 ACI proportional lowest point -100.00–100.00% 0.00
