Chapter 11 Summary of Parameter SettingsC2000-HS
11-49
14 Extension Card Parameter
Pr. Parameter Name Setting Range Default

14-00
Extension card Input terminal
selection (AI10)
0: Disable
1: Frequency command
0

14-01
Extension card Input terminal
selection (AI11)
2: Torque command (torque limit under speed mode)
3: Torque compensation command
0
4: PID target value
5: PID feedback signal
6: Thermistor (PTC / KTY-84) input value
7: Positive torque limit
8: Negative torque limit
9: Regenerative torque limit
10: Positive/ negative torque limit
11: PT100 thermistor input value
13: PID compensation amount

14-08 Analog input filter time (AI10) 0.00–20.00 sec. 0.01

14-09 Analog input filter time (AI11) 0.00–20.00 sec. 0.01

14-10
Analog input 4–20mA signal loss
selection (AI10)
0: Disable
1: Continue operation at the last frequency
2: Decelerate to 0Hz
3: Stop immediately and display ACE
0

14-11
Analog input 4–20mA signal loss
selection (AI11)
0

14-12
Extension card output terminal
selection (AO10)
0: Output frequency (Hz)
1: Frequency command (Hz)
0

14-13
Extension card output terminal
selection (AO11)
2: Motor speed (Hz)
3: Output current (rms)
0
4: Output voltage
5: DC BUS voltage
6: Power factor
7: Power
8: Torque
9: AVI
10: ACI
11: AUI
12: Iq current command
13: Iq feedback value
14: Id current command
15: Id feedback value
18: Torque command
19: PG2 frequency command
20: CANopen analog output
