Chapter 11 Summary of Parameter SettingsC2000-HS
11-50
Pr. Parameter Name Setting Range Default
21: RS-485 analog output
22: Communication card analog output
23: Constant voltage output
25: CANopen and RS-485 analog output

14-14
Analog output 1 gain output
(AO10)
0.0–500.0% 100.0

14-15
Analog output 1 gain output
(AO11)
0.0–500.0% 100.0

14-16
Analog output 1 in REV direction
(AO10)
0: Absolute value of output voltage
1: Reverse output 0V; Forward output 0–10V
2: Reverse output 5–0V; Forward output 5–10V
0

14-17
Analog output 1 in REV direction
(AO11)
0

14-18
Extension card input selection
(AI10)
0: 0–10V (AVI10)
1: 0–20mA (ACI10)
2: 4–20mA (ACI10)
0

14-19
Extension card input selection
(AI11)
0: 0–10V (AVI11)
1: 0–20mA (ACI11)
2: 4–20mA (ACI11)
0
14-20 AO10 DC output setting level 0.00–100.00 % 0.00
14-21 AO11 DC output setting level 0.00–100.00 % 0.00

14-22
AO10 filter output time
0.00–20.00 sec. 0.01

14-23
AO11 filter output time
0.00–20.00 sec. 0.01

14-36
AO10 output selection
0: 0–10V
1: 0–20mA
2: 4–20mA
0

14-37
AO11 output selection
0
