Chapter 12 Description of Parameter SettingsC2000-HS
12.1-00-2

Start-up Display Selection
Default: 0
Settings 0: F (frequency command)
1: H (output frequency)
2: U (user-defined) Pr.00-04
3: A (output current)
 This parameter determines the start-up display page. This is the user-defined choice display
according to the setting in Pr. 00-04.

Content of Multi-function Display
Default: 3
Settings 0: Display output current (A) (Unit: Amp)
1: Display counter value (c) (Unit: CNT)
2: Display actual output frequency (H.) (Unit: Hz)
3: Display DC BUS voltage (v) (Unit: V
DC
)
4: Display output voltage (E) (Unit: V
AC
)
5: Display output power angle (n) (Unit: deg)
6: Display output power in kW (P) (Unit: kW)
7: Display actual motor speed rpm (r = 00: positive speed; -00 negative
speed) (Unit: rpm)
8: Display estimate output torque % (t = 00: positive torque; -00 negative
torque) (t) (Unit: %)
9: Display PG feedback (G) (refer to Pr. 10-00 and Pr. 10-01) (Unit: PLS)
10: Display PID feedback (b) (Unit: %)
11: Display AVI in % (1.) (Unit: %)
12: Display ACI in % (2.) (Unit: %)
13: Display AUI in % (3.) (Unit: %)
14: Display the temperature of IGBT (i.) (Unit: °C)
15: Display the temperature of capacitance (c.) (Unit: °C)
16: The status of digital input (ON/OFF) refer to Pr. 02-12 (i) (Refer to
Note3)
17: Display digital output status ON/OFF (Pr. 02-18) (o) (refer to NOTE 4)
18: Display the multi-step speed that is executing (S)
19: The corresponding CPU pin status of digital input (d) (refer to NOTE 3)
20: The corresponding CPU pin status of digital output (0.) (refer to NOTE
4)
21: Actual motor position (PG1 of PG card). (Max. 32bits display) (P.)
22: Pulse input frequency (PG2 of PG card) (S.)
23: Pulse input position (PG2 of PG card) (Max. 32bits display) (q.)
24: Position command tracing error (E.)
25: Overload counting (0.00–100.00%) (o.) (Unit: %)
26: GFF Ground Fault (G.) (Unit: %)
27: DC BUS voltage ripple (r.) (Unit: V
DC
)
