Chapter 12 Description of Parameter SettingsC2000-HS
12.1-00-3
28: Display PLC register D1043 data (C)
29: Display PM motor pole section (EMC-PG01U application) (4.)
30 : Display output of user defined (U)
31 : Display Pr. 00-05 user gain (K)
32: Number of actual motor revolution during operation (PG card plug in
and Z phase signal input) (Z.)
33: Motor actual position during operation (when PG card is connected)(q)
34: Operation speed of fan (F.) (Unit: %)
35: Control Mode display: 0 = Speed control mode (SPD), 1 = torque
control mode (TQR) (t.)
36: Present operating carrier frequency of drive (Hz) (J.)
38: Display drive status (6.) (Refer to Note 7)
39: Display of estimated output torque, positive and negative (t=0.0:
positive torque; -0.0: negative torque) (C.) (unit: Nm-t)
40
: Torque command (L.) (Unit: %)
41
: kWh display (J) (Unit: kWh)
42: PID target value (h.) (Unit: %)
43: PID offset (o.) (Unit: %)
44: PID output frequency (b.) (Unit: Hz)
45: Hardware ID
49: Motor temperature (PTC, PT100, KTY84-130)
51: PMSVC torque offset
52: AI10%
53: AI11%
54: PMFOC Ke estimated value
Explanation 1
When Pr. 10-01 is set to 1000 and Pr. 10-02 is set to 1 & 2, the displayed range for PG feedback
is between 0–4000.
When Pr. 10-01 is set to 1000 and Pr. 10-02 is set to 3, 4 & 5, the displayed range for PG
feedback is between 0–1000.
Home position: If it has Z phase, the Z phase is regarded as home position. Otherwise, home
position will be the encoder start up position.
Explanation 2
It can also display negative values when setting analog input bias (Pr. 03-03–03-10).
Example: Assume that AVI input voltage is 0V, Pr. 03-03 is 10.0%, Pr. 03-07 is 4 (Bias serves as
the center), and Pr. 03-10 is 1 allowing negative frequency input.
Explanation 3
Example: If REV, MI1 and MI6 are ON, the following table shows the status of the terminals.
Normally opened contact (N.O.) (0: OFF, 1: ON)
Terminal MI15 MI14 MI13 MI12 MI11 MI10 MI8 MI7 MI6 MI5 MI4
MI3
MI2 MI1 REV FWD
Status 0 0 0 0 0 0 0 0 1 0 0 0 0
1 1 0
