Chapter 12 Description of Parameter SettingsC2000-HS
12.1-06-12
Fault Code
bit0 bit1 bit2 bit3 bit4 bit5 bit6
current Volt. OL SYS FBK EXI CE
21: Drive over-load (oL)
●
22: Electronics thermal relay protection 1 (EoL1)
●
23: Electronics thermal relay 2 protection (EoL2)
●
24: Motor PTC overheat (oH3) (PTC / PT100)
●
26: Over-torque 1 (ot1)
●
27: Over-torque 2 (ot2)
●
28: Low current (uC)
●
29: Home limit error (LMIT)
●
30: Memory write-in error (cF1)
●
31: Memory read-out error (cF2)
●
33: U-phase current detection error (cd1)
●
34: V-phase current detection error (cd2)
●
35: W-phase current detection error (cd3)
●
36: Clamp current detection error (Hd0)
●
37: Over-current detection error (Hd1)
●
38: Over-voltage detection error (Hd2)
●
39: IGBT short-circuit detection error (Hd3)
●
40: Auto-tuning error (AUE)
●
41: PID feedback loss (AFE)
●
42: PG feedback error (PGF1)
●
43: PG feedback loss (PGF2)
●
44: PG feedback stall (PGF3)
●
45: PG slip error (PGF4)
●
48: Analog current input loss (ACE)
●
49: External fault input (EF)
●
50: Emergency stop (EF1)
●
51: External Base Block (bb)
●
52: Password error (Pcod)
●
54: Communication error (CE1)
●
55: Communication error (CE2)
●
56: Communication error (CE3)
●
57: Communication error (CE4)
●
58: Communication time-out (CE10)
●
60: Brake transistor error (bF)
●
61: Y-connection/∆-connection switch error (ydc)
●
62: Deceleration Energy Backup error (dEb)
●
63: Slip error (oSL)
●
64: Electromagnet switch error (ryF)
●
