Chapter 12 Description of Parameter SettingsC2000-HS
12.1-06-13
Fault Code
bit0 bit1 bit2 bit3 bit4 bit5 bit6
current Volt. OL SYS FBK EXI CE
65: PG Card Error (PGF5)
●
68: Sensorless estimated speed have wrong
direction
●
69: Sensorless estimated speed is over speed
●
70: Sensorless estimated speed deviated
●
72: Channel 1 (STO1–SCM1) safety loop error
(STL1)
●
73: External safety gate S1
●
75: external brake error
●
76: Safe Torque Off (STO)
●
77: Channel 2 (STO2–SCM2) safety loop error
(STL2)
●
78: Internal loop error (STL3)
●
82: U phase output phase loss (OPHL)
●
83: V phase output phase loss (OPHL)
●
84: W phase output phase loss (OPHL)
●
85: PG-02U ABZ hardware disconnection
●
86: PG-02U UVW hardware disconnection
●
89: Initial rotor position detection error
●
90: Inner PLC function is forced to stop
●
101: CANopen software disconnect 1 (CGdE)
●
102: CANopen software disconnect 2 (CHbE)
●
104: CANopen hardware disconnect (CbFE)
●
105: CANopen index setting error (CldE)
●
106: CANopen slave station number setting error
(CAdE)
●
107: CANopen index setting exceed limit (CFrE)
●
111: Internal communication overtime error (ictE)
●
112: PM sensorless shaft Lock error
●

PTC Detection Selection / PT100 Motion
Default: 0
Settings 0: Warn and continue operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning
 Sets the operation mode of a drive after you set Pr. 06-29 to define PTC / PT100 / KTY84
detection.
