Modbus
address
RW Function
2205H R Power angle (XXX.X)
2206H R Display actual motor speed kW of U, V, W (XXXXX kW)
2207H R
Display motor speed in rpm estimated by the drive or encoder feedback
(XXXXX rpm)
2208H R
Display positive/negative output torque in %, estimated by the drive (t0.0:
positive torque, -0.0: negative torque) (XXX.X %)
2209H R Display PG feedback (see NOTE 1 in Pr. 00-04)
220AH R PID feedback value after enabling PID function (XXX.XX %)
220BH R
Display signal of AVI analog input terminal, 0–10V corresponds to
0.00–100.00% (1.) (see NOTE 2 in Pr. 00-04)
220CH R
Display signal of ACI analog input terminal, 4–20mA / 0–10V corresponds to
0.00–100.00% (2.) (see NOTE 2 in Pr. 00-04)
220DH R
Display signal of AUI analog input terminal, -10V–10V corresponds to
-100.00–100% (3.) (see NOTE 2 in Pr. 00-04)
220EH R IGBT temperature of drive power module (XXX.X ºC)
220FH R The temperature of capacitance (XXX.X ºC)
2210H R
The status of digital input (ON/OFF), refer to Pr. 02-12
(see NOTE 3 in Pr. 00-04)
2211H R
The status of digital output (ON/OFF), refer to Pr. 02-18
(see NOTE 4 in Pr. 00-04)
2212H R The multi-step speed that is executing (S)
2213H R
The corresponding CPU pin status of digital input (d.)
(see NOTE 3 in Pr. 00-04)
2214H R
The corresponding CPU pin status of digital output (O.)
(see NOTE 4 in Pr. 00-04)
2215H R
Number of actual motor revolution (PG1 of PG card) (P.) it starts from 9
when the actual operation direction is changed or the keypad displays at
stop is 0. The maximum is 65535
2216H R Pulse input frequency (PG2 of PG card) (XXX.XX Hz)
2217H R Pulse input position (PG card PG2), the maximum setting is 65535.
2218H R Position command tracing error
2219H R Display times of counter overload (XXX.XX %)
221AH R GFF (XXX.XX %)
221BH R DCBUS voltage ripples (XXX.X V)
221CH R PLC register D1043 data (C)
221DH R Number of poles of a permanent magnet motor
221EH R User page displays the value in physical measure
221FH R Output Value of Pr. 00-05 (XXX.XX Hz)
2220H R
Number of motor turns when drive operates (saves when drive stops, and
resets to zero when operating)
2221H R
Operating position of the motor (saves when drive stops, and resets to zero
when operating)
2222H R Fan speed of the drive (XXX %)
2223H R Control mode of the drive 0: speed mode 1: torque mode
2224H R Carrier frequency of the drive (XX kHz)
2225H R Reserve
2226H R
Drive
status
bit1–0
00b: No direction
01b: Forward
10b: Reverse
bit3–2 01b: Drive ready
10b: Error
bit4 0b: Motor drive did not output
1b: Motor drive did output
