Delta VFD110VL43C-J User Manual

Appendix B: CANopen Overview | VFD-VJ
Apx B - 16
Index Sub Definition
Factory
Setting
R/W Size Note
input terminal, 4~20mA/
0–10 V corresponds to
0–100%
(to two decimal places)
D
Display signal of PI analog
input terminal, 0~10 V
corresponds to 0 ~100%
(to
two decimal places)
0 R U16
F
Display the IGBT
temperature of drive power
module (XXX.X
o
C)
0 R U16
10
Display motor drive’s
capacitor temperature
(XXX.X
o
C)
0 R U16
11
The status of digital input
(ON/OFF), refer to Pr.02-12
0 R U16
12
The status of digital output
(ON/OFF), refer to Pr.02-18
0 R U16
13
Reserved
0 R U16
14
The corresponding CPU pin
status of digital input
0 R U16
15
The corresponding CPU pin
status of digital output
0 R U16
16
Reserved
0 R U16
17
Reserved
0 R U16
18
Reserved .
0 R U16
1A
Display signal of QI analog
input terminal, 0~10 V
corresponds to 0 ~100% (to
two decimal places)
0 R U16
1B
Display actual pressure
(Bar)
0 R U16
1C
Display kw/ hr
0 R U16
1D
Display motor’s
temperature ºC
0 R U16
1E
Display motor drive’s over
load in %
0 R U16
1F
Display motor’s over load in
% of HES type A
0 R U16
20
Display current at braking
(Ampere)
0 R U16
21
Display braking chopper’s
temperature ºC
0 R U16
