Delta VFD110VL43C-J User Manual

VFD-VJ-C | Appendix C: MSJ 220V & 380V Hybrid Servo Motor
Apx C-12

C-6-3: Encoder Cable (CBHE-E5M)
220V & 380V:
(tin coated)
KTY- (black/ white)
KTY+ (red/ white)
PTC (yellow/ black)
PTC (yellow)
○
1
SCSI(MDR) Plug
<Drive Side>
○
2
MDR Shell with SCSI
terminal
○
3
Cable
○
4
Strain Relief
○
5
Military Connector
<Motor Side>
○
6
Cable Tie
