Chapter 3. Machine Adjustment Procedure | VFD-VJ
3-19
3-4 Confluence Machine Tuning Procedure
Wiring according to Chapter 2
Carry out the automatic measurement of the motor’s parameters according to Step 1 and Step 2
described above for the Master and Slave, respectively. Then perform the following procedure
Master setting
Set Pr.03-13 = 1
Confluence Master/Slave Selection
Setting value
of Pr.03-13
0: No function
1: Master 1
2: Slave/Master 2
3: Slave/Master 3
Set Pr.03-14
Slave's proportion of the Master’s flow
Setting value
of Pr.03-14
0.0~6553.5%
Pr.03-17 can be configured to determine the activation level of the Slave
Slave’s activation level
Setting value
of Pr.03-17
0~100%
