Delta VFD150VL43A-J User Manual

2. Wiring
2-5
PI
QI
MI
PI
QI
03 13 2 -=
03 13 2 -=
SG+
SG-
SG+
SG-
SG+
SG-
SG+
SG-
03 13 3 -=
M M
M M
PO
PO
03 13 1 -=
Mater 1
Slave Slave
Mater 3
Hydraulic outlet 1
Hydraulic outlet 2
Pressure
Command
Flow
Command
Pressure
Command
Flow Command
Combined/Divert
Signals
When the signals are confluence, the communication will be a short circuit
When the signals are diversion, the communication becomes an open circu
i
- .
;
The wiring of main circuit and control circuit should be separated to prevent
erroneous actions.
;
Please use shield wire for the control wiring and not to expose the peeled-off net in
front of the terminal.
;
Please use the shield wire or tube for the power wiring and ground the two ends of
the shield wire or tube.
;
Make sure that the leads are connected correctly and the AC drive is properly
grounded. (Ground resistance should not exceed 0.1
Ω
.)
;
Use ground leads that comply with local regulations and keep them as short as
possible.
;
Multiple VFD-VJ units can be installed in one location. All the units should be
grounded directly to a common ground terminal, as shown in the figure below.
Ensure there are no ground loops.
Excellen
t
Grounding terminals
