Chapter 3. Machine Adjustment Procedure | VFD-VJ
3-10
Induction motor
 Set Pr.01-00 = 0
Control mode
Setting value
of Pr. 01-00
0: VF
1: Reserved
2: Reserved
3: FOC vector control + Encoder (FOCPG)
4: Reserved
5: FOCPM
6: Reserved
 Set Pr.01-26 = 0
Encode type
Setting value
of Pr.01-26
0: ABZ
1: ABZ+HALL (only used for Delta’s servo motors)
2: ABZ+HALL
3:Resolver
 Set Pr.01-29
Number of pulses for each revolution of the encoder
Setting value
of Pr.01-29
1~20000
 Set Pr. 01-08
The rated current of the induction motor
Setting value
of Pr. 01-08
0~655.35 Amps
 Set Pr.01-09
The rated power of the induction motor
Setting value
of Pr.01-09
0.00 – 655.35kW
 Set Pr.01-10
The rated speed (rpm) of the induction motor
Setting value
of Pr.01-10
0~65535
 Set Pr.01-11
Number of poles of the induction motor
Setting value
of Pr.01-11
2~20
 Check if the motor can be separated from the pump
1. If it can be separated, set Pr.01-07 as 1 and carry out a dynamic measurement
2. If it cannot be separated, open the safety valve, enter the no-load current of the induction
motor Pr.01-12 and set Pr.01-07 as 2. Then carry out the static measurement
