Chapter 3. Machine Adjustment Procedure | VFD-VJ
3-12
Synchronous motor
 Set Pr.01-00 = 5
Control mode
Setting value
of Pr.01-00
0: VF
1: Reserved
2: Reserved
3: FOC vector control + Encoder (FOCPG)
4: Reserved
5: FOCPM
6: Reserved
 Set Pr.01-26 = 3
Encode type
Setting value
of Pr.01-26
0: ABZ
1: ABZ+HALL (only used for Delta’s servo motors)
2: ABZ+HALL
3:Resolver
 Set Pr.01-29
Number of pulses for each revolution of the encoder
Setting value
of Pr.01-29
1~20000
 Set Pr.01-17
The rated current of the synchronous motor
Setting value
of Pr.01-17
0~655.35 Amps
 Set Pr.01-18
The rated power of the synchronous motor
Setting value
of Pr.01-18
0.00 – 655.35kW
 Set Pr.01-19
The rated speed (rpm) of the synchronous motor
Setting value
of Pr.01-19
0~65535
 Set Pr.01-20
Number of poles of the synchronous motor
Setting value
of Pr.01-20
2~20
