Chapter 12 Descriptions of Parameter SettingsMS300
443
Analog input selection (AVI)
Analog input selection (ACI)
AVI terminal input selection
ACI terminal input selection
Analog input curve selection
1 (three-point curve of AVI)
Restart after momentary power loss
2 (Speed tracking by the minimum output
frequency)
Number of times of restart after fault
Auto-restart interval of fault
Setting 04: Pump
The following table lists the relevant pump setting application parameters.
Master frequency command source
(AUTO, REMOTE)
2 (External analog input)
Operation command source
(AUTO, REMOTE)
Motor 1 maximum operation frequency
Rated / base frequency of motor 1
Rated / base voltage of motor 1
Mid-point frequency 1 of motor 1
Mid-point voltage 1 of motor 1
Mid-point frequency 2 of motor 1
Mid-point voltage 2 of motor 1
Minimum output frequency of motor 1
Minimum output voltage of motor 1
Output frequency upper limit
Output frequency lower limit
2 (V/F curve to the power of 2)
Restart after momentary power loss
2 (Speed tracking by the minimum output
frequency)
Number of times of restart after fault
Auto-restart interval of fault
To Next Page
