Delta VFD220C4EA-21 - Page 92

Chapter 5 Main Circuit TerminalsC2000 Plus
5-15
Frame F
R/L1 T/L3 V/T2S/L2 U/T1 W/T3
 If you install at Ta 40°C (for 230V / 460V model names with last digit -21; for 690V model names
end with 63B-21)
/ 50°C (for 230V / 460V model names with last digit -00; for 690V model names
end with 63B-00)
environment, use copper wires have a voltage rating of 600V and are
temperature resistance to 75°C
or 90°C.
 If you install at Ta 40°C (for 230V / 460V model names with last digit -21; for 690V model names
end with 63B-21)
/ 50°C (for 230V / 460V model names with last digit -00; for 690V model names
end with 63B-00) above environment, use copper wires have a voltage rating of 600V and are
temperature resistant ntance to 90°C or above.
 For VFD900C23A-00 models: if you install at Ta 45°C above environment, use copper wires that
have a voltage rating of 600V and are temperature resistance to 90°C or above.
 For VFD900C23E-21 models: if you install at Ta 30°C above environment, use copper wires that
have a voltage rating of 600V and are temperature resistance to 90°C or above.
 To be UL installation compliant, you must use copper wires when installing. The wire gauge is
based on temperature resistance of 75°C, in accordance with
UL requirements and
recommendations. Do not reduce the wire gauge when using high-temperature resistant wire.
Model Name
Main Circuit Terminals
R/L1、S/L2、T/L3、U/T1、V/T2、W/T3、
-/DC-、+1/DC+
Terminal
Max. Wire
Gauge
Min. Wire Gauge
Screw
Spec. and
Torque
(±10%)
Max. Wire Gauge Min. Wire Gauge
Screw Spec.
and Torque
(±10%)
VFD900C23A-00
150 mm
2
*2
(300
MCM*2)
150 mm
2
*2
(300MCM*2)
M8
180 kg-cm
(156.2
lb-in.)
(17.65 Nm)
1
50 mm
2
*2 (300 MCM*2)
150 mm
2
*1 (300 MCM*1)
M8
180 kg-cm
(156.2 lb-in.)
(17.65 Nm)
VFD1320C43A-00
1
20 mm
2
*2 (4/0 AWG*2) 120 mm
2
*2 (4/0 AWG*2)
120 mm
2
*1 (4/0 AWG*1)
VFD1600C43A-00
150 mm
2
*2
(300MCM*2)
1
50 mm
2
*2 (300 MCM*2)
150 mm
2
*1 (300 MCM*1)
VFD900C23A-21
120 mm
2
*2
(4/0 AWG*2)
1
20 mm
2
*2 (4/0 AWG*2) 120 mm
2
*2 (4/0 AWG*2)
120 mm
2
*1 (4/0 AWG*1)
VFD1320C43A-21 95 mm
2
*2 (3/0 AWG*2) 95 mm
2
*2 (3/0 AWG*2)
95 mm
2
*1 (3/0 AWG*1)
VFD1600C43A-21
1
20 mm
2
*2 (4/0 AWG*2) 120 mm
2
*2 (4/0AWG*2)
120 mm
2
*1 (4/0 AWG*1)
VFD1600C63B-00
150 mm
2
*2
(300
MCM*2)
70 mm
2
*2 (2/0 AWG*2) 70 mm
2
*2 (2/0 AWG*2)
70 mm
2
*1 (2/0 AWG*1)
VFD2000C63B-00 95 mm
2
*2 (3/0 AWG*2) 95 mm
2
*2 (3/0 AWG*2)
95 mm
2
*1 (3/0 AWG*1)
VFD1600C63B-21 70 mm
2
*2 (2/0 AWG*2) 70 mm
2
*2 (2/0 AWG*2)
70 mm
2
*1 (2/0 AWG*1)
VFD2000C63B-21 95 mm
2
*2 (3/0 AWG*2) 95 mm
2
*2 (3/0 AWG*2)
95 mm
2
*1 (3/0 AWG*1)
