Delta VFD2A8MS21ANSAA User Manual

Chapter 11 Summary of Parameter SettingsMS300
236
Pr.
Explanation
Settings
Default
81: W-phase Over-current before run (coc)
82: Output phase loss U phase (oPL1)
83: Output phase loss V phase (oPL2)
84: Output phase loss W phase (oPL3)
87: Low frequency overload protection (oL3)
89: Rotor position detection error (roPd)
101: CANopen guarding error (CGdE)
102: CANopen heartbeat error (CHbE)
104: CANopen bus off error (CbFE)
105: CANopen index error (CidE)
106: CANopen station address error (CAdE)
107: CANopen index setting exceed limit (CFrE)
121: Internal communication error (CP20)
123: Internal communication error (CP22)
124: Internal communication error (CP30)
126: Internal communication error (CP32)
127: Internal communication error (CP33)
128: Over-torque 3 (ot3)
129: Over-torque 4 (ot4)
134: Internal communication error (EoL3)
135: Internal communication error (EoL4)
140: oc hardware error (Hd6)
141: GFF occurs before run (b4GFF)
142: Auto-tune error 1 (AuE1)
143: Auto-tune error 2 (AuE2)
144: Auto-tune error 3 (AuE3)
149: Auto-tune error 5 (AuE5)

06-23
Fault Output Option 1
0–65535 (refer to bit table for fault code)
0

06-24
Fault Output Option 2
0–65535 (refer to bit table for fault code)
0

06-25
Fault Output Option 3
0–65535 (refer to bit table for fault code)
0

06-26
Fault Output Option 4
0–65535 (refer to bit table for fault code)
0

06-27
Electronic Thermal Relay
Selection 2 (Motor 2)
0: Inverter motor (with external forced cooling)
1: Standard motor (motor with fan on the shaft)
2: Disabled
2

06-28
Electronic Thermal Relay
Action Time 2 (Motor 2)
30.0–600.0 sec.
60.0

06-29
PTC Detection Selection
0: Warn and continue operation
1: Fault and ramp to stop
2: Fault and coast to stop
3: No warning
0
