Chapter 12 Descriptions of Parameter SettingsMS300
262
contents display according to the Pr.00-04 settings.
Content of Multi-function Display (User-Defined)
0: Display output current (A) (Unit: Amp)
1: Display counter value (c) (Unit: CNT)
2: Display the drive’s actual output frequency (H.) (Unit: Hz)
3: Display the drive’s DC bus voltage (v) (Unit: V
DC
)
4: Display the drive’s output voltage (E) (Unit: V
AC
)
5: Display the drive’s output power angle (n) (Unit: deg)
6: Display the drive’s output power (P) (Unit: kW)
7: Display the motor speed (r) (Unit: rpm)
8: Display the drive’s estimated output torque, motor’s rated torque is 100%
(t) (Unit: %)
10: Display PID feedback (b) (Unit: %)
11: Display AVI analog input terminal signal (1.) (Unit: %)
12: Display ACI analog input terminal signal (2.) (Unit: %)
14: Display the drive’s IGBT temperature (i.) (Unit:
o
C)
16: The digital input status (ON / OFF) (i)
17: The digital output status (ON / OFF) (o)
18: Display multi-step speed (S)
19: The corresponding CPU digital input pin status (d)
20: The corresponding CPU digital output pin status (0.)
22: Pulse input frequency (S.)
25: Overload count (0.00–100.00%) (o.) (Unit: %)
26: Ground Fault GFF (G.) (Unit: %)
27: DC bus voltage ripple (r.) (Unit: V
DC
)
28: Display PLC register D1043 data (C)
30: Display the output of User-defined (U)
31: Display Pr.00-05 user gain (K)
35: Control mode display:
0 = Speed control mode (SPD)
1 = Torque control mode (TQR) (t.)
36: Present operating carrier frequency of the drive (J.) (Unit: Hz)
38: Display the drive status (6.) (Refer to Explanation 6 below)
39: Display the drive’s estimated output torque, positive and negative,
using Nt-m as unit (t 0.0: positive torque; -0.0: negative torque) (C.)
40: Torque command (L.) (Unit: %)
41: kWh display (J) (Unit: kWh)
42: PID target value (h.) (Unit: %)
43: PID compensation (o.) (Unit: %)
44: PID output frequency (b.) (Unit: Hz)
