Chapter 14 Fault CodesMS300
584
ID
Display on LCD Keypad
Fault Name
Fault Descriptions
45
PG slip error
(PGF4)
Under PG mode, when the motor frequency exceeds
encoder observer slip range (Pr.10-13) and starts to
count, the fault time is longer than the detection time of
encoder observer slip (Pr.10-14), PGF4 fault occurs.
Action and Reset
Action Condition
Pr.10-13
Action Time
Pr.10-14
Fault Treatment Parameter
Pr.10-15
0: Warn and continue operation
1: Fault and ramp to stop
2: Fault and coast to stop
Reset Method
Auto
When Pr.10-15 = 0, PGF4 is a “Warning”. When the deviation
between the output frequency and motor frequency is smaller than the
encoder observer slip range, the warning is automatically cleared.
Manual
When Pr.10-15 = 1 or 2, PGF4 is a “Fault”. You must reset manually.
Reset Condition
Immediately reset
Record
When Pr.10-15 = 1 or 2, PGF4 is a “Fault”, and the fault is recorded.
Cause
Corrective Actions
Incorrect settings for PG feedback
parameters
Reset correct values for Pr.10-13 and Pr.10-14.
Incorrect settings for ASR
parameters and accel./decel. time
Reset ASR parameters.
Set correct accel./decel time.
Incorrect settings of encoder
parameters
Reset encoder parameters (Pr.10-01).
Accel./Decel. time is too short
Reset proper accel./decel. time.
Incorrect settings of torque limit
parameters (Pr.06-12,Pr.11-17–20)
Reset proper setting values for Pr.06-12 and Pr.11-17–Pr.11-20.
Motor shaft lock
Remove causes of motor shaft lock.
Mechanical brake is not released
Check the action timing of the system.
