Chapter 7 Optional AccessoriesMS300
78
DC Reactor:
Figure 7-20
DC Reactors
Delta Part #
Rated
Current
(Arms)
Saturation
Current
(Arms)
DC
Reactors
(mH)
A
(mm)
B
(mm)
C
(mm)
D
(mm)
E
(mm)
R
(mm)
DR005D0585
5
8.64
5.857
79
78
112
64±2
56±2
9.5*5.5
DR008D0366
8
12.78
3.660
79
78
112
64±2
56±2
9.5*5.5
DR011D0266
11
18
2.662
79
92
112
64±2
69.5±2
9.5*5.5
DR017D0172
17
28.8
1.722
79
112
112
64±2
89.5±2
9.5*5.5
DR025D0117
25
43.2
1.172
99
105
128
79±2
82.5±2
9.5*5.5
DR033DP851
33
55.8
0.851
117
110
156
95±2
87±2
10*6.5
DR049DP574
49
84.6
0.574
117
120
157
95±2
97±2
10*6.5
DR065DP432
65
111.6
0.432
117
140
157
95±2
116.5±2
10*6.5
DR003D1870
3
5.22
18.709
79
78
112
64±2
56±2
9.5*5.5
DR004D1403
4
6.84
14.031
79
92
112
64±2
69.5±2
9.5*5.5
DR006D0935
6
10.26
9.355
79
92
112
64±2
69.5±2
9.5*5.5
DR009D0623
9
14.58
6.236
79
112
112
64±2
89.5±2
9.5*5.5
DR010D0534
10.5
17.1
5.345
99
93
128
79±2
70±2
9.5*5.5
DR012D0467
12
19.8
4.677
99
105
128
79±2
82.5±2
9.5*5.5
DR018D0311
18
30.6
3.119
117
110
144
95±2
87±2
10*6.5
DR024D0233
24
41.4
2.338
117
120
144
95±2
97±2
10*6.5
DR032D0175
32
54
1.754
117
140
157
95±2
116.5±2
10*6.5
DR038D0147
38
64.8
1.477
136
135
172
111±2
112±2
10*6.5
DR045D0124
45
77.4
1.247
136
135
173
111±2
112±2
10*6.5
Table 7-36
