Delta VFD300C43S-HS User Manual

Chapter 11 Summary of Parameter SettingsC2000-HS
11-3
Pr. Parameter Name Setting Range Default
38: Display drive status (6.)
39: Display estimated output torque, positive and
negative, using Nt-m as unit (t 0.0: positive
torque; -0.0: negative torque (C.)
40: Torque command (L.) (Unit: %)
41: kWh display (J) (Unit: kWh)
42: PID target value (h.) (Unit: %)
43: PID offset (o.) (Unit: %)
44: PID output frequency (b.) (Unit: Hz)
45: Hardware ID
49: Motor temperature (PTC, PT100, KTY84-130)
51: PMSVC torque offset
52: AI10%
53: AI11%
54: PMFOC Ke estimated value

00-05
Coefficient gain in actual output
frequency
0.00–160.00 1.00
00-06 Software version Read only
Read
only

00-07
Parameter protection password
input
0–65535
0–4: the number of password attempts allowed
0

00-08
Parameter protection password
setting
0–65535
0: No password protection / password entered
correctly (Pr. 00-07)
1: Password has been set
0
00-10 Control mode
0: Speed mode
1: Point-to-point position control mode
2: Torque mode
3: Homing mode
0
00-11 Speed control mode
0: IMVF (IM V/F control)
1: IMVFPG (IM V/F control + Encoder)
2: IM/PM SVC (IM / PM space vector control)
3: IMFOCPG (IM FOC + Encoder)
4: PMFOCPG (PM FOC + Encoder)
5: IMFOC sensorless (IM FOC sensorless )
6: PM sensorless (PM FOC sensorless)
7: IPM sensorless (Interior PM FOC sensorless)
0
00-12 Point-to-point position mode
0: Relative position
1: Absolute position
0
