Chapter 12 Description of Parameter SettingsC2000-HS
12.1-03-21
AI Lower Level
Default: 10.00
Settings -100.00–100.00 %
Multi-function output terminal 67 must work with Pr.03-44 to select input channels. When analog
input level is higher than Pr.03-45, multi-function output acts; when analog input level is lower
than Pr.03-46, multi-function output terminals stop outputting.
When setting levels, AI upper level must be higher than AI lower level.
Analog Input Curve Selection
Default: 0
Settings 0: Regular Curve
1: Three-point curve of AVI
2: Three-point curve of ACI
3: Three-point curve of AVI & ACI
4: Three-point curve of AUI
5: Three-point curve of AVI & AUI
6: Three-point curve of ACI & AUI
7: Three-point curve of AVI & ACI & AUI
Sets the calculation method for analog input.
When Pr. 03-50 = 0, all analog input signal is calculated by bias and gain.
When Pr. 03-50 = 1, AVI calculates by frequency and voltage / current (Pr. 03-51–03-56), other
analog input signal calculates by bias and gain.
When Pr. 03-50 = 2, ACI consulates by frequency and voltage / current (Pr. 03-57–03-62), other
analog input signal calculates by bias and gain.
When Pr. 03-50 = 3, AVI and ACI calculate by frequency and voltage/ current (Pr. 03-51–03-62),
other analog input signal calculates by bias and gain.
When Pr. 03-50 = 4, AVI calculates by frequency and voltage / current (Pr. 03-63–03-74), other
analog input signal calculates by bias and gain.
When Pr. 03-50 = 5, AVI and AUI calculate by frequency and voltage / current (Pr. 03-51–03-56
and 03-63–03-74), other analog input signal calculates by bias and gain.
When Pr. 03-50 = 6, ACI and AVI calculate by frequency and voltage / current (Pr. 03-57–03-74),
other analog input signal calculates by bias and gain.
When Pr. 03-50 = 7, all analog input signal calculate by frequency and voltage / current (Pr.
03-51–03-74).
AVI Lowest Point
Default:
0.00 / 0.00 / 4.00
Settings Pr. 03-28 = 0, 0.00–10.00V
Pr. 03-28 = 1, 0.00–20.00mA
Pr. 03-28 = 2, 0.00–20.00mA
