Chapter 2. Wiring | VFD-VJ

2-17
VJ-A and VJ-C Air Cooled

Frame D



Main Circuit Terminals:
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3, DC+, DC-,
B1, B2
Grounding Terminal:

Models
Max. Wire
Gauge
Mini. Wire
Gauge
Screw Size
and
Torque Force
 (± 10%)
Max.
Wire
Gauge

Mini.
Wire
Gauge

Screw Size
and
Torque
Force
(± 10%)

VFD150VL23A-J
35 mm
2
(2 AWG)


35 mm
2
(2 AWG)
M6
50 kg-cm
(43.4 lb-in)
(4.9 Nm
35 mm
2
(2 AWG)

35 mm
2
(2 AWG)

M6
50 kg-cm
(43.4
lb-in.)
(4.9 Nm)
VFD185VL23A-J
35 mm
2
(2 AWG)

35 mm
2
(2 AWG)

35 mm
2
(2 AWG)

VFD220VL23A-J
35 mm
2
( 2 AWG)
35 mm
2
(2 AWG)

35 mm
2
(2 AWG)

VFD300VL43C-J
35 mm
2
(2 AWG)
35 mm
2
(2 AWG)
16 mm
2
(6 AWG)
VFD370VL43C-J
35 mm
2
(2 AWG)
35 mm
2
(2 AWG)
16 mm
2
(6 AWG)

NOTE:
1.  If you install at Ta 45°C environment, select copper wire with voltage rating of 600 V and temperature
resistance of 75°C or 90°C
2.  If you install at Ta 45°C above environment, select copper wire with voltage rating of 600 V and temperature
resistance of 90°C or above.
3.  For UL installation compliance, use copper wires when installing. The wire gauge is based on a temperature
resistance of 75°C, in accordance with UL requirements and recommendations.
4.  Do not reduce the wire gauge when using higher temperature wire.
5.  For VFD220VL43A-J model, if you install it at Ta 30°C above environment, select copper wire with voltage
rating of 600V and temperature resistance of 90°C or above.
