Chapter 2 Installation and Wiring_VFD-B Series
Revision 10/2005, BE13, SW V4.08 2-11
Frame F: VFD550B43A, VFD750B43A
130.4 [5.13]
280.0 [11.02]
1
8
.
0
[
0
.7
1
]
18.0 [0.71]
660.0 [25.98]
385.0 [15.16]
425.0 [16.73] 264.0 [10.39]
R6.5[0.25]
13.0[0.51]
21.0[0.83]
631.0 [24.84]
13
.
0
[
0
.
5
1
]
7
4.
8
[
2.94
]
2
2.0
[
0
.87]
