Delta VFD370C43S-HS User Manual

Chapter 12 Description of Parameter SettingsC2000-HS
12.1-02-18
Settings Functions Descriptions
50
Output control for
CANopen
Control the multi-function output terminals through CANopen.
To control RY2, set Pr. 02-14 = 50.
The mapping table of the CANopen DO is shown in the following
table:
Physical
terminal
Setting of related
parameters
Attribute Corresponding Index
RY1 Pr. 02-13 = 50 RW The bit0 at 2026-41
RY2 Pr. 02-14 = 50 RW The bit1 at 2026-41
MO1 Pr. 02-16 = 50 RW The bit3 at 2026-41
MO2 Pr. 02-17 = 50 RW The bit4 at 2026-41
MO10
Pr. 02-36 = 50 RW
The bit5 at 2026-41
RY10 The bit5 at 2026-41
MO11
Pr. 02-37 = 50 RW
The bit6 at 2026-41
RY11 The bit6 at 2026-41
RY12 Pr. 02-38 = 50 RW The bit7 at 2026-41
RY13 Pr. 02-39 = 50 RW The bit8 at 2026-41
RY14 Pr. 02-40 = 50 RW The bit9 at 2026-41
RY15 Pr. 02-41 = 50 RW The bit10 at 2026-41
Refer to Chapter 15-3-5 for more information.
51
Analog output control for
RS-485 interface
For RS-485 interface (InnerCOM / MODBUS) communication
control output.
Physical
terminal
Setting of related
parameters
Attribute
Corresponding
index
RY1 Pr. 02-13 = 51 RW The bit0 at 2640H
RY2 Pr. 02-14 = 51 RW The bit1 at 2640H
MO1 Pr. 02-16 = 51 RW The bit3 at 2640H
MO2 Pr. 02-17 = 51 RW The bit4 at 2640H
MO10 or RA10 Pr. 02-36 = 51 RW The bit5 at 2640H
MO11 or RA11 Pr. 02-37 = 51 RW The bit6 at 2640H
RA12 Pr. 02-38 = 51 RW The bit7 at 2640H
RA13 Pr. 02-39 = 51 RW The bit8 at 2640H
RA14 Pr. 02-40 = 51 RW The bit9 at 2640H
RA15 Pr. 02-41 = 51 RW The bit10 at 2640H
52
Output control for
communication cards
Control the output through communication cards (CMC-MOD01,
CMC-EIP01, CMC-PN01 and CMC-DN01)
Physical
terminal
Setting of related
parameters
Attribute
Corresponding
Address
RY1 Pr. 02-13 = 51 RW The bit0 at 2640H
RY2 Pr. 02-14 = 51 RW The bit1 at 2640H
RY3 Pr. 02-15 = 51 RW The bit2 at 2640H
MO1 Pr. 02-16 = 51 RW The bit3 at 2640H
MO2 Pr. 02-17 = 51 RW The bit4 at 2640H
MO3 Pr. 02-18 = 51 RW The bit5 at 2640H
MO4 Pr. 02-19 = 51 RW The bit6 at 2640H
MO5 Pr. 02-20 = 51 RW The bit7 at 2640H
MO6 Pr. 02-21 = 51 RW The bit8 at 2640H
MO7 Pr. 02-22 = 51 RW The bit9 at 2640H
MO8 Pr. 02-23 = 51 RW The bit10 at 2640H
