Delta VFD370C43S-HS User Manual

Chapter 12 Description of Parameter SettingsC2000-HS
12.1-09-9
Modbus
address
R/W Function
2101H R
bit1–0
AC motor drive operation status
00B: Drive stops
01B: Drive decelerating
10B: Drive standby
11B: Drive operating
bit2
1：JOG Command
bit4–3
Operation Direction
00B: FWD run
01B: From REV run to FWD run
10B: From FWD run to REV run
11B: REV run
bit8 1: Master frequency controlled by communication interface
bit9 1: Master frequency controlled by analog/external signal
bit10 1: Operation command controlled by communication interface
bit11 1: Parameter locked
bit12 1: Enable to copy parameters from keypad
bit15–13 Reserved
2102H R Frequency command (XXX.XX Hz)
2103H R Output frequency (XXX.XX Hz)
2104H R
Output current (XX.XX A). When current is higher than 655.35, it shifts the
decimal as (XXX.X A). The decimal can refer to High byte of 211F.
2105H R DC BUS Voltage (XXX.X V)
2106H R Output voltage (XXX.X V)
2107H R Current step number of multi-step speed operation
2108H R Reserved
2109H R Counter value
210AH R Power factor angle (XXX.X)
210BH R Output torque (XXX.X %)
210CH R Actual motor speed (XXXXX rpm)
210DH R Number of PG feedback pulses (0–65535)
210EH R Number of PG2 pulse commands (0–65535)
210FH R Power output (X.XXX kW)
2116H R Multi-function display (Pr. 00-04)
211BH R
Maximum Operation Frequency (Pr. 01-00) or Maximum User-defined Value
(Pr. 00-26)
When Pr. 00-26 is 0, this value is equal to Pr. 01-00 setting
When Pr. 00-26 is not 0, and the command source is keypad, this value =
Pr. 00-24 * Pr. 00-26 / Pr. 01-00
When Pr. 00-26 is not 0, and the command source is 485, this value = Pr.
09-10 * Pr. 00-26 / Pr. 01-00
211FH R High byte: decimal of current value (display)
Status monitor read only (22xx)
Modbus
address
RW Function
2200H R
Display output current (A). When current is higher than 655.35, it shifts the
decimal as (XXX.X A). The decimal can refer to High byte of 211F.
2201H R Display counter value (c)
2202H R Actual output frequency (XXXXX Hz)
2203H R DC BUS voltage (XXX.X V)
2204H R Output voltage (XXX.X V)
