Delta VFD4A8MS21ANSAA User Manual

Chapter 7 Optional AccessoriesMS300
61
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Input /
Output
Reactor
(mH)
AC Input Reactor
AC Output Reactor
DC
Reactor
(mH)
DC Reactor
Delta Part #
Delta Part #
Weight
(kg)
Delta Part #
Weight
(kg)
VFD25AMS23ANSAA
VFD25AMS23ENSAA
27
40.5
0.32
DR033AP320
4.5
DR033LP320
6.5
1.172
DR025D0117
VFD33AMS23ANSAA
VFD33AMS23ENSAA
36
54
0.216
DR049AP215
6.5
DR049LP215
8.6
0.851
DR033DP851
VFD49AMS23ANSAA
VFD49AMS23ENSAA
51
76.5
0.216
DR049AP215
6.5
DR049LP215
8.6
0.574
DR049DP574
VFD65AMS23ANSAA
VFD65AMS23ENSAA
69
103.5
0.169
DR075AP170
10
DR075LP170
14.5
0.432
DR065DP432
Table 7-16
230V, 50–60 Hz / Three-phase - Heavy Duty
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Input /
Output
Reactor
(mH)
AC Input Reactor
AC Output Reactor
DC
Reactor
(mH)
DC Reactor
Delta Part #
Delta Part #
Weight
(kg)
Delta Part #
Weight
(kg)
VFD1A6MS23ANSAA
VFD1A6MS23ENSAA
1.6
3.2
2.536
DR005A0254
1.2
DR005L0254
1.5
5.857
DR005D0585
VFD2A8MS23ANSAA
VFD2A8MS23ENSAA
2.8
5.6
2.536
DR005A0254
1.2
DR005L0254
1.5
5.857
DR005D0585
VFD4A8MS23ANSAA
VFD4A8MS23ENSAA
4.8
9.6
2.536
DR005A0254
1.2
DR005L0254
1.5
5.857
DR005D0585
VFD7A5MS23ANSAA
VFD7A5MS23ENSAA
7.5
15
1.585
DR008A0159
1.7
DR008L0159
2.5
3.66
DR008D0366
VFD11AMS23ANSAA
VFD11AMS23ENSAA
11
22
1.152
DR011A0115
2.5
DR011L0115
3.0
2.662
DR011D0266
VFD17AMS23ANSAA
VFD17AMS23ENSAA
17
34
0.746
DR017AP746
3.2
DR017LP746
3.6
1.722
DR017D0172
VFD25AMS23ANSAA
VFD25AMS23ENSAA
25
50
0.507
DR025AP507
3.8
DR025LP507
5.5
1.172
DR025D0117
VFD33AMS23ANSAA
VFD33AMS23ENSAA
33
66
0.32
DR033AP320
4.5
DR033LP320
6.5
0.851
DR033DP851
VFD49AMS23ANSAA
VFD49AMS23ENSAA
46
92
0.216
DR049AP215
6.5
DR049LP215
8.6
0.574
DR049DP574
VFD65AMS23ANSAA
VFD65AMS23ENSAA
65
130
0.163
DR065AP162
8.5
DR065LP162
12
0.432
DR065DP432
Table 7-17
460V, 50–60 Hz / Three-phase - Normal Duty
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Input /
Output
Reactor
(mH)
AC Input Reactor
AC Output Reactor
DC
Reactor
(mH)
DC Reactor
Delta Part #
Delta Part #
Weight
(kg)
Delta Part #
Weight
(kg)
VFD1A5MS43ANSAA
VFD1A5MS43ENSAA
VFD1A5MS43AFSAA
1.8
2.7
8.102
DR003A0810
1.5
DR003L0810
1.5
18.709
DR003D1870
VFD2A7MS43ANSAA
VFD2A7MS43ENSAA
VFD2A7MS43AFSAA
3
4.5
6.077
DR004A0607
1.8
DR004L0607
2.5
18.709
DR003D1870
