Chapter 7 Optional AccessoriesMS300
62
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Input /
Output
Reactor
(mH)
AC Input Reactor
AC Output Reactor
DC
Reactor
(mH)
DC Reactor
Delta Part #
Delta Part #
Weight
(kg)
Delta Part #
Weight
(kg)
VFD4A2MS43AFSAA
VFD4A2MS43ANSAA
VFD4A2MS43ENSAA
4.6
6.9
4.05
DR006A0405
2.8
DR006L0405
3.0
14.031
DR004D1403
VFD5A5MS43AFSAA
VFD5A5MS43ANSAA
VFD5A5MS43ENSAA
6.5
9.75
2.7
DR009A0270
3.5
DR009L0270
3.6
9.355
DR006D0935
VFD7A3MS43ANSAA
VFD7A3MS43ENSAA
VFD7A3MS43AFSAA
8.9
13.35
2.7
DR009A0270
3.5
DR009L0270
3.6
6.236
DR009D0623
VFD9A0MS43AFSAA
VFD9A0MS43ANSAA
VFD9A0MS43ENSAA
10.5
15.75
2.315
DR010A0231
4.5
DR010L0231
5.5
5.345
DR010D0534
VFD13AMS43AFSAA
VFD13AMS43ANSAA
VFD13AMS43ENSAA
15.7
23.55
1.174
DR018A0117
5.3
DR018L0117
6.4
3.119
DR018D0311
VFD17AMS43AFSAA
VFD17AMS43ANSAA
VFD17AMS43ENSAA
20.5
30.75
0.881
DR024AP881
5.8
DR024LP881
7.2
3.119
DR018D0311
VFD25AMS43AFSAA
VFD25AMS43ANSAA
VFD25AMS43ENSAA
28
42
0.66
DR032AP660
9
DR032LP660
11
2.338
DR024D0233
VFD32AMS43AFSAA
VFD32AMS43ANSAA
VFD32AMS43ENSAA
36
54
0.639
DR038AP639
9.5
DR038LP639
12
1.754
DR032D0175
VFD38AMS43AFSAA
VFD38AMS43ANSAA
VFD38AMS43ENSAA
41.5
62.25
0.541
DR045AP541
10.5
DR045LP541
16
1.477
DR038D0147
VFD45AMS43AFSAA
VFD45AMS43ANSAA
VFD45AMS43ENSAA
49
73.5
0.405
DR060AP405
11.5
DR060LP405
18
1.247
DR045D0124
Table 7-18
460V, 50–60 Hz / Three-phase - Heavy Duty
Model
Rated
Current
(Arms)
Saturation
Current
(Arms)
Input /
Output
Reactor
(mH)
AC Input Reactor
AC Output Reactor
DC
Reactor
(mH)
DC Reactor
Delta Part #
Delta Part #
Weight
(kg)
Delta Part #
Weight
(kg)
VFD1A5MS43ANSAA
VFD1A5MS43ENSAA
VFD1A5MS43AFSAA
1.5
3
8.102
DR003A0810
1.5
DR003L0810
1.5
18.709
DR003D1870
VFD2A7MS43ANSAA
VFD2A7MS43ENSAA
VFD2A7MS43AFSAA
2.7
5.4
8.102
DR003A0810
1.5
DR003L0810
1.5
18.709
DR003D1870
VFD4A2MS43AFSAA
VFD4A2MS43ANSAA
VFD4A2MS43ENSAA
4.2
8.4
6.077
DR004A0607
1.8
DR004L0607
2.5
14.031
DR004D1403
VFD5A5MS43AFSAA
VFD5A5MS43ANSAA
VFD5A5MS43ENSAA
5.5
11
4.05
DR006A0405
2.8
DR006L0405
3.0
9.355
DR006D0935
VFD7A3MS43ANSAA
VFD7A3MS43ENSAA
VFD7A3MS43AFSAA
8.1
16.2
2.7
DR009A0270
3.5
DR009L0270
3.6
6.236
DR009D0623
